The two-phase battery installation at the refinery site.
Overview
Unilam Pressings is a leading steel-components manufacturer with a large factory in southern Johannesburg. Repeated vandalism of grid infrastructure forced the operation to rely on diesel generators at a cost of hundreds of thousands of US dollars per year. The solar-plus-storage system was designed to lower energy cost when the grid is available and reduce generator use during frequent outages.
Client Request
01. Provide fast transfer for a 340 kVA industrial load.
02. Support 12 hours of operation without the grid and with minimal diesel-generator assistance.
03. Reduce peak and standard-time grid energy use by 90% when the grid is available.
04. Integrate automatic generator start and stop.
Project Solution
— Solar array — 660 kWp
— PCS + MPPT — 500 kW
— Battery system — 1,505 kWh (768 V / 280 Ah × 7 sets)
— Diesel genset — 800 kVA
REVO supplies complete PV and storage stacks for distributors, EPCs and system integrators that need bankable product families and engineering support.
